Fore Innovations 2015-2017 Mustang GT L4 Whipple E85 Fuel System

Return fuel system capable of 1200+ rwhp with triple fuel pumps. (recommend running one pump full time, then activating secondary pumps under load.) Fuel rails in parallel with regulator after rails. Includes in-tank supply system that retains OE transfer, fuel level senders, and EVAP functionality, upgraded feed, and return lines, monoblock Coyote fuel rails, y-block, high capacity filtration and check valve, and high capacity F2i regulator with boost reference.

Fuel system becomes E85 capable by choosing F90000267, F90000274, and F90000285 fuel pumps AND micro glass SSD or stainless filtration.

INCLUDES

• S197C / S550 Fuel Pump Module (triple pump)
• F2i Fuel Pressure Regulator
• 2011-2017 Coyote Billet Fuel Rails
• 2-1 compact billet Y-block
• FCV Check valve
• All fittings, hose, and hardware necessary to complete typical fuel line plumbing
• 30′ of fuel line of your choice
• Qty 14, compression-style billet hose ends
• Qty 8, straight AN to o-ring fittings
• Qty 2, 1.25″ fuel rail extensions
• Qty 6, billet low profile 90º AN to o-ring fittings
• Qty 2, billet low profile 180º fittings
• Qty 10, hose straps with stainless mounting screws
• Qty 2, 1/8 NPT plugs

This is a stand alone fuel system. Professional installation and a custom tune are required. Qualified installers and tuners must be able to interface to the OE harness and FPDM, understand proper component placement hose routing and deliver the vehicle with factory-like pump prime/on/off logic with no error codes. Fore Innovations will supply basic system schematics and detailed component level instructions and can troubleshoot the performance and function of our system and components.

This fuel system generates substantially more heat and capacity than the original fuel system. The high-powered fuel pumps make much more heat than the factory pump and the composite fuel tank construction acts as an insulator and stores heat. The factory fuel tank’s shape also limits this fuel system’s pickup capacity. The user (driver) must keep more fuel (than normal) in the tank at all times to minimize heat damage and ensure adequate fuel pickup.

---
