Smaller. Lighter. Faster.

Turbosmart’s turbocharger series is engineered for those who demand peak performance and reliability—whether on the track or the street. Using cutting-edge materials, advanced design, and modern manufacturing, the TS-1 turbochargers deliver outstanding transient response and power in a compact, lightweight package.

What’s Included

Every Turbosmart turbocharger comes standard with:

• Weld flanges

• V-band clamps

• Gaskets

• Oil feed and drain fittings

TS-1 Series Features

• Oil-cooled turbochargers

• Lightweight 310S stainless steel investment-cast turbine housings

• Proprietary dual ceramic bearing system and main shaft assembly for ultra-fast spool

• 7+7 2618 aluminum splitter wheels for aggressive compressor aerodynamics

• 713C Inconel turbine wheel built to handle extreme EGTs

• CFD-optimized housings for maximum flow and efficiency

• Integrated iron backplate on center housing

• VSR speed balanced for reliability at high RPMs

• Lightweight aluminum compressor covers

Performance Advantages

• Unparalleled transient response

• High power output with lower shaft speeds

• Reduced backpressure, increased flow efficiency

• Designed to be smaller, lighter, and faster than competing solutions

• Ideal for motorsports and high-performance street builds

Available Options

• TS-1 (oil cooled)

• TS-2 (oil + water cooled)

• V-Band, T3, and T4 flange options

• Reverse rotation (select sizes)

• Multiple A/R options

• Internal and external wastegate configurations

Specifications

• Compressor Inlet: 4″ (101.6mm)

• Compressor Inducer: 78mm

• Turbine Inlet: V-Band (3.00″)

• Turbine Exducer: 80mm

• Turbine A/R: 0.96

• Turbine Outlet: V-Band (3.50″)

• Weight: 9.63 kg / 21.23 lbs

• Horsepower Rating: 1140–1350 HP
