CSF 2015-2025 Ford F-150 & Raptor High-Performance Transmission Oil Cooler
or as low as $33.25/mo with Affirm
Available
CSF High-Performance Transmission Oil Cooler — 2015-2025 F-150 & Raptor
The CSF #8102 transmission oil cooler delivers a 40% increase in cooling capacity over the OEM unit using proprietary AC Condenser Technology. Whether you’re towing heavy, hauling equipment, or pushing your truck hard off-road, this cooler prevents transmission fluid from overheating and protects your 10-speed automatic.
Features
- +40% Cooling Capacity — Dramatically outperforms both standard and Tow Package OEM coolers
- AC Condenser Technology — Super-high pressure 26mm 10-channel microtube design maximizes oil flow and surface area
- 7 Cooling Tubes — vs. 4 (standard) or 6 (tow package) from factory
- 8×8mm Cooling Fin Rows — Tube & fin core construction for efficient heat transfer
- Plug-and-Play Installation — 15-30 minute install, no modifications required
- 2-Year Manufacturer Warranty
Specifications
- Design: 1-Row Super-High Pressure 26mm 10-Channel Microtube
- Cooling Tubes: 7
- Fin Rows: 8×8mm
- Part Number: CSF #8102
Fitment
- 2015-2025 Ford F-150 2.7L EcoBoost
- 2015-2025 Ford F-150 3.5L EcoBoost
- 2015-2025 Ford F-150 5.0L V8
- 2017-2025 Ford F-150 Raptor 3.5L EcoBoost
⚠️ Critical Fitment Note — Towing Package Required: This cooler is a direct plug-and-play replacement ONLY on trucks equipped with the Heavy Duty Towing Package (also called Max Tow Package or Trailer Tow Package). These trucks have a factory front-mounted transmission oil cooler (Ford P/N FL3Z-7A095-A or HL3Z-7A095-A) that the CSF #8102 directly replaces.
Base trucks without the Towing Package use only a smaller transmission-mounted cooler (ML3Z-7869-C) and do NOT have the front-mount cooler. Installing the CSF #8102 on a base truck requires additional parts, brackets, and hard lines ($300-500+ in additional cost) to route fluid to the front-mount location. Contact us for guidance if you’re unsure which cooling setup your truck has.
Pairs perfectly with the CSF #8095 All-Aluminum Radiator for a complete cooling solution.
