Fortune Auto 2020-2024 Ford Explorer ST (U625) - 500 Series Coilovers
510 Series Coilovers are custom, hand-built to order. Most applications have a 4-7 week lead time. Lead times for certain applications and peak season orders may vary.
Key Features
-
High-flow digressive single-adjustable 500 Series coilover system for Explorer ST
-
24-step damping gives flexible tuning for both street comfort and occasional track use
-
High-pressure monotube design with nitrogen for consistent performance under load
-
T6 6061 aluminum mounts for strength and lightness
-
Fully rebuildable and revalveable for long-term serviceability
-
Modular upgrade path: compatible with 2-way or 3-way canister setups
or as low as $164.83/mo with Affirm
Fortune Auto 500 Series — Explorer ST
Single-adjustable monotube for the 2020-2024 Explorer ST (U625) — 6K/12K Swift-rear spec. The family hauler that corners. Custom. Modular. Rebuildable.
Buy once. Never buy coilovers again.
Fortune Auto engineers are consistently chasing improvement, and the Generation 8 500 Series is the proof. Every set is hand-assembled to your order, dyno-tested with a printed curve, and built on a platform you can rebuild, revalve and upgrade instead of replace.
The Explorer ST application ships at 6K front / 12K rear (Swift rear spring standard) — dialed for the U625’s weight without killing the daily ride. Custom rates? Call 805-267-9762.
Street vs. Track — why digressive wins
Race-track R&D tuned for the street: optimized for comfort, reliability and longevity. Rides like a quality OEM sport setup — until you ask for more.
Stiff low-speed compression and rebound control roll, dive and squat — while fast shaft speeds stay supple over curbs and bumps for maximum grip.
What every 500 Series ships with
- High Flow Digressive™ piston technology
- FA synthetic shock oil
- Custom-built & shock-dyno tested in the USA
- T6-6061 aluminum mounts & camber plates
- Koyo Japan radial bearing mounts
- Premium chrome silicon springs w/ locking perches
- Fully rebuildable & revalveable (Richmond, VA)
- Modular — upgradeable to 2-way / 3-way canister
High Flow Digressive™ piston
The force/velocity curve says it all: strong low-speed force for body control, then the curve flattens so fast hits stay supple. That’s the digressive advantage.
Anatomy of the 500
In the box & on the bench
Specifications
- Damper
- Monotube, high-pressure nitrogen
- Adjustment
- 24-step (single-adjustable)
- Piston
- High Flow Digressive™
- Oil
- FA synthetic shock oil
- Mounts
- T6-6061 + camber plates
- Rates
- 6K front · 12K rear (Swift)
- Includes
- Complete coilover set, ready to bolt on
- Build
- Custom order · dyno-tested · Richmond VA
- Service
- Rebuildable & revalveable USA
- Modularity
- 2-way / 3-way canister upgrade path
- Warranty
- 5-year limited
Spring upgrades: pick Default, Swift (+$200) or Hyperco (+$200) fronts in the dropdown above. Custom rates for your build — call 805-267-9762 before ordering.
