This 2015-2020 Ford Mustang GT single valve Plug N Play ™ catch can kit with adjustable mounting bracket is the perfect fit for your engine bay. With its extremely efficient compact design and Incredible Looks. UPR went the extra mile to ensure you get the best quality components. Utilizing Continental Braided Hose and Billet Hose Ends to give you the Strongest and Best Performing Setup Possible. No cheap stock lines here that have been cut and spliced on! Featuring the New UPR Plug N Play ™ Catch Can Fittings. So you can empty it without removing the intake cover or catch can line from your engine. (UPR Exclusive Push Button Fittings) UPR has hundreds of hours testing their new Multi-Stage Oil Separator to ensure the claims and results will exceed your expectations. They even doubled the size of the oil containment chamber. The design of this unit is more along the lines of a True Engineer and cannot be compared or confused with units that have side-by-inlets and outlets with screens rolled up and shoved in them. The Multi-chamber technology in UPR catch cans captures and filters all the oil vapor and trash from getting into your air intake tract. That’s the most important reason for a catch can in the first place! Don’t forget the UPR CSS – Clean Side Separator for the Driver side of the PCV system to make sure you are fully protected at both ends of the PCV system. (Great protection and ideal for all driving situations) Manufactured from Domestic T-6 6061 Aluminum bar stock and finished off using only the best Diamond cutters to exceed your expectations of what a superior product should fit and look like. UPR is the largest aftermarket catch can manufacturer in the country. Continually improving their designs to stay ahead of the competition and give you the cutting-edge technology of tomorrow today.
THIS PART DOES NOT CARRY AN CARB EO NUMBER, AND THEREFORE IS FOR RACING / OFF-ROAD USE ONLY. NOT FOR SALE OR USE IN CALIFORNIA DUE TO CARB/EMISSIONS. ALL CALIFORNIA ORDERS WILL BE CANCELLED AND REFUNDED
Upgrades available:
UPR Billet Pro Series Check Valves:
These are larger, higher flowing check valves than the standard check valve normally installed in the hoses during assembly. Check valves only allow airflow in one direction, so it will prevent intake pulses and reversion from entering the catch can, and in boosted applications, it will prevent boost pressure from leaking past and pressurizing the catch can and crankcase. The larger check valves will increase the vacuum through the catch can and deliver better crankcase evacuation. The improved crankcase evacuation translates to increased MPG and more responsive low-speed drivability.
UPR SS Magnetic Drain Plug:
The Stainless Steel magnetic drain plug would replace the drain plug on the bottom of the catch can with an Allen head plug that has a magnet embedded into it. It will attract any ferrous metal material to it so the user can inspect it.
UPR Catch Can Drain Line Kit:
The drain line kit includes a drain valve, hose, and fittings needed to install the drain valve. It allows the user to relocate the drain somewhere easier to access like the wheel well opening or bumper area.
**You would select either the Stainless Steel Magnetic Drain Plug or The Catch Drain Line Kit, not both. If neither is selected, the catch can will have a standard plug installed.
Product Features:
» 8oz Capacity
» Show Quality Finish
» Can measures 2.5″ x 6″
» Prevents Oil from Entering Intake
» Exclusive Multi-Stage Design Traps Oil
» Innovative Diffuser Tube and Chamber
» High Quality CNC Machined Billet Aluminum
» Plug N Play ™ fittings at Catch Can connections
» 5/8″ Oil Resistant Continental Braided Hose included
» Innovative Adjustable Mounting Bracket (360° Rotation)
» Improves Fuel Economy, Throttle Response & Performance
» Available in Satin, Polished or Black – Select Finish Above
» Available with Driver Clean Side Separator (Tall or Short) – Select Option Above
Installation:
Installs in 15 minutes.
Includes:
» Billet Check Valve
» OEM 5/8″ Factory Connectors
» 5/8″ Continental Braided Hoses
» Billet Hose Ends with Clamps
» Billet Adjustable Mounting Bracket
» Plug N Play ™ quick release connectors & billet fittings
» Single Valve Billet Catch Can (Exclusive 4 Stage Design
Fitment:
2015-2020 Ford Mustang GT 5.0 Coyote S550
Fits Right Hand Drive models as well
