The UPR Plug N Play™ Catch Can Features Multiple Chambers and a pressed Coalescing Filter that delivers optimal performance. Plug N Play™ Fittings, adjustable brackets, and UPR’s Billet LT4 PCV Diverter are just a few of the features that make this kit head and shoulders above the rest. The fittings are all quick-release Plug n Play™ fittings that allow you to push the buttons to release the catch can in seconds without any tools.

UPR’s Dual Valve catch can deliver exceptional performance and utilizes all the best components, and hoses, and fittings. No plastic or rubber hoses with cheap worm clamps or plastic fittings like many catch can manufacturers use to make more profit on inferior products. UPR uses billet fittings, braided hoses, custom-fit billet hose ends to lock the hoses and fittings in place. We’ve been working on better options for the GM vehicles to make Enthusiasts aware of the Ineffective performance of the 2-chamber catch cans others offer. They’re all just inferior copies of one another without any improvements to the major design differences to improve their oil separation. These 2 Chambers Pull Through Oil Catch Can run Generic Screens, Compressor Filters, and Honeycomb Filters such as JLT – Moroso – Mishimoto Catch Cans. These designs reduce cost and deliver a reduction in performance as well.

2 Chamber Designs have been proven to allow as much oil into the intake as they collect in the can still allowing 50% or more of the oil to be ingested filling the manifold and causing detonation/spark knock in the cylinder. Mainly because the design requires a better-engineered diffuser system and not just a simple screen, muffler, or honeycomb filter. The primary function of an oil separation system is to eliminate fuel degradation and any possibility of engine knock known as detonation from oil entering the combustion chamber. It’s not how much you collect in the Catch Can it’s how much you stop from exiting the exit stream of the Catch Can.

THIS PART DOES NOT CARRY AN CARB EO NUMBER, AND THEREFORE IS FOR RACING / OFF-ROAD USE ONLY.  NOT FOR SALE OR USE IN CALIFORNIA DUE TO CARB/EMISSIONS. ALL CALIFORNIA ORDERS WILL BE CANCELLED AND REFUNDED

This UPR Pro Series catch can kit is shipped ready to install even if no upgrades are selected. Upgrades are available to allow you to tailor the kit to fit your needs. See the description below and select any upgrades from the drop-down menus.

Upgrades available:

The Billet Pro Series check valve is a larger, higher-flowing check valve than our standard check valve.  It generally will increase the vacuum through the catch can and equate to better PCV evacuation.  Better evacuation can translate to better MPG and low-speed drivability. If you plan on adding a Supercharger or Turbo kit, this is recommended.

The One-way crankcase breather is a breather with a one-way valve in it.  It allows excess crankcase pressure to exit through the breather filter when needed and will close when crankcase pressure is normal, which keeps unmetered air from entering.  Installation can’t be easier!  Just remove your oil fill cap and install the UPR Billet One Way Breather.  Highly recommended on Boosted engines.

The Stainless Steel magnetic drain plug would replace the drain plug on the bottom of the catch can with an Allen head plug that has a magnet embedded into it. It will attract any ferrous metal material to it so the user can inspect it.

The drain line kit includes a drain valve, hose, and fittings needed to install the drain valve. It allows the user to relocate the drain somewhere easier to access like the wheel well opening or bumper area.  (You would choose either the Magnetic Drain Plug or the Drain line kit – not both.  If no drain option is selected, a standard plug will be installed)

The UPR catch cans have an O ring seal on the containment cup.  Replacement O rings are available if you lose, drop, or tear an O ring when servicing the catch can.  It’s not a bad idea to have a spare set in the glove box.

Features:

» Billet Hose Ends

» Plug N Play Fittings

» Show Quality Machine Finish

» Billet Catch Can Size 3″ x 6″

» Multi-Chamber Billet Catch Can

» Adjustable Mounting Bracket

» Continental Instagrip Braided Hose

» 12 Ounce Oil Capacity Holds the Most Oil in it’s Class

» Available in Black Anodized Finish

» Includes the Billet LT4 PCV diverter. (Required for installation)
