UPR Products 2016-2021 Ford Mustang GT350 / Mach 1 Single Valve Oil Catch Can with CSS Plug N Play

This 2016 to Present Ford Mustang GT350 / Mach 1 Single Valve Plug N Play ™ Catch Can Kit & Clean Side Separator with adjustable mounting bracket is the perfect fit for your engine bay. With its extremely efficient compact design and Incredible Looks. We went the extra mile to ensure you get the best quality components. Utilizing Continental Braided Hose and Billet Hose Ends to give you the Strongest and Best Performing Setup Possible. No cheap stock lines here that have been cut and spliced on! Featuring the New UPR Plug N Play ™ Catch Can Fittings. So you can empty it without removing the intake cover or catch can lines from your engine. (UPR Exclusive Push Button Fittings) We have hundreds of hours testing our new 4 Stage Oil Separator to ensure the claims and results will exceed your expectations. We even double the size of the oil containment chamber. The design of this unit is more along the lines of a True Engineer and cannot be compared or confused with units that have side-by-inlets and outlets with screens rolled up and shoved in them. The 4 chamber technology in UPR catch cans captures and filters all the oil vapor and trash from getting into your air intake tract. That’s the most important reason for a catch can in the first place! Manufactured from Domestic T-6 6061 Aluminum bar stock and finished off using only the best Diamond cutters to exceed your expectations of what a superior product should fit and look like. UPR is the largest aftermarket catch can manufacturer in the country. Continually improving our designs to stay ahead of the competition and give you the cutting-edge technology of tomorrow today.

THIS PART DOES NOT CARRY AN CARB EO NUMBER, AND THEREFORE IS FOR RACING / OFF-ROAD USE ONLY.  NOT FOR SALE OR USE IN CALIFORNIA DUE TO CARB/EMISSIONS. ALL CALIFORNIA ORDERS WILL BE CANCELLED AND REFUNDED

Product Details:

» 8oz Capacity

» Show Quality Finish

» Can measures 2.5″ x 6″

» Prevents Oil from Entering Intake

» Exclusive 4 Stage Design Traps Oil

» Innovative Diffuser Tube and Chamber

» High Quality CNC Machined Billet Aluminum

» Plug N Play ™ fittings at Catch Can connections

» 5/8″ Oil Resistant Continental Braided Hose included

» Innovative Adjustable Mounting Bracket (360° Rotation)

» Improves Fuel Economy, Throttle Response & Performance

The Billet Pro Series check valve is a larger, higher flowing check valve than our standard check valve.  It generally will increase the vacuum through the catch can and equate to better PCV evacuation.  Better evacuation can translate to better MPG and low-speed drivability.

The Stainless Steel magnetic drain plug would replace the drain plug on the bottom of the catch can with an Allen head plug that has a magnet embedded into it. It will attract any ferrous metal material to it so the user can inspect it.

The drain line kit includes a drain valve, hose, and fittings needed to install the drain valve. It allows the user to relocate the drain somewhere easier to access like the wheel well opening or bumper area.

The One-way crankcase breather is a breather with a one-way valve in it.  It allows excess crankcase pressure to exit through the breather when needed.  It will close when crankcase pressure is normal, and keep unmetered air from entering. This crankcase pressure relief is beneficial to rings and seals.  The filter element is washable with warm water and mild detergent.

The Adjustable Billet PCV fitting is made to accept replaceable jets. It eliminates the failure-prone factory PCV, adds flow adjustment, and still allows for the needed restriction since it is not always a good idea to use a ‘gutted’ or open PCV valve fitting.   This is beneficial to supercharge, turbocharged, and track day cars.  It Includes 4 different size jets. Jet sizes and application basics for the adjustable version are explained below:

» .100 Jet size is slightly more restrictive than the factory PCV fitting to allow you to restrict the PCV for vehicles ingesting too much oil through the PCV and wanting to reduce oil consumption.

» .125 Jet size is slightly less restrictive than the factory PCV fitting to allow you to adjust the PCV to increase flow a bit more than factory for vehicles that only need minor adjustments to eliminate vapor locking in the PCV system.

» .150 Jet size is even less restrictive for the boosted vehicles that tow and are driven harder to increase flow more than factory for vehicles that only need more adjustment to eliminate vapor locking in the PCV system.

» .175 Jet size is the least restrictive compared to the factory PCV fitting and allows for the largest adjustment of the jets for modified vehicles that generate a lot of blow-by/backpressure to eliminate vapor locking / flooding the clean side of the PCV system with oil.

Includes:

» Billet Check Valve

» 5/8″ Continental Braided Hoses

» Billet Adjustable Mounting Bracket

» Plug N Play ™ quick release connectors & billet fittings

» Single Valve Billet Catch Can (Exclusive 4 Stage Design)

» Clean Side Separator (Multi-Stage Filtration) New Low Profile Design

Installation –

Installs in 20 minutes or less.

Click Here for Instructions
