Whipple Superchargers 2016-2020 Ford Shelby GT350 / GT350R 5.2L Gen 6 3.0L Supercharger Kit
Complete Gen 6 W185ax 3.0L twin-screw system for the 2016-2020 GT350/GT350R – up to 875 HP on 93 octane, 50-state legal (CARB D-231-87), HP Tuners MPVI4 + Whipple cal included. PN WK-2621-30.
Whipple Gen 6 3.0L — Shelby GT350 / R
The W185ax twin-screw that turns the flat-plane 5.2L Voodoo into an 875-horsepower street weapon — the most powerful 50-state-legal system you can bolt to a GT350. Complete kit, PN WK-2621-30.
An entirely different league.
The GT350 and GT350R are already special cars — a properly engineered Whipple twin-screw takes the 5.2L platform somewhere else entirely. Instant torque, violent mid-range pull, and a relentless charge to the 8,250 rpm redline, while keeping the refinement a premium Shelby build deserves.
Since 1987, Whipple has led twin-screw supercharging. The Gen 6 W185ax 3.0L moves more air with less effort than 1.9L/2.3L roots systems — 30% more displacement means lower discharge temps and less parasitic loss. On 93 octane, the complete system supports up to 875 HP and 660 lb-ft. No other upgrades required.
Daily refinement. 875 HP violence. Pick both.
OEM-grade drivability with the oversized intercooled air-bypass cutting burst knock, parasitic loss and even improving cruise fuel economy. It idles, it commutes, it behaves — on factory-feeling manners.
More boost at the hit than any competing twin-screw, a dead-flat torque curve, and the patented dual-core dual-pass intercooler keeping charge temps down when heat becomes the enemy. The Voodoo finally gets the midrange it deserved.
What’s in the box
- Whipple Gen 6 W185ax 3.0L twin-screw, front-entry
- Oversized Crusher™ inlet + Roval 150mm inlet
- Billet 132mm Roval electronic throttle body
- 123mm high-flow air intake system
- Patented dual-core, dual-pass air-to-water intercooler
- ~150% larger heat exchanger volume + high-flow pump
- Oversized intercooled air-bypass system
- Self-contained oversized oil system
- Billet fuel rails + high-flow injectors
- HP Tuners MPVI4 + Whipple calibration support
- Spark plugs included
- Complete kit — nothing else required
Engineered as one system
Every piece — blower, inlet, intercooling, fuel, calibration — is designed and assembled at Whipple’s Fresno facility to work as one system. This is not a kit built around generic parts.
Up close
Specifications
- Part Number
- WK-2621-30
- Power
- Up to 875 HP / 660 lb-ft (93 octane*)
- Supercharger
- Gen 6 W185ax — 3.0L twin-screw, front entry
- Emissions
- 50-state legal — CARB EO D-231-87
- Throttle Body
- Billet 132mm Roval electronic
- Intake
- 123mm high-flow + Roval 150mm inlet
- Intercooler
- Dual-core dual-pass air-to-water
- Fuel
- Billet rails + high-flow injectors
- Tuning
- HP Tuners MPVI4 + Whipple calibration
- Ship Weight
- 149 lbs · 36″ × 24″ × 18″
- Manufactured
- Fresno, California, USA
Calibration: the included HP Tuners MPVI4 + Whipple cal support get you running right. Questions on tune strategy or install? Call 805-267-9762 — we sell what we wrench on.
