BorgWarner EFR 6258 0.64 a/r T25 Internal Wastegate Turbocharger

History
Did you realize BorgWarner’s origins can take us back all the way to 1880?  The BorgWarner we all know about today started in 1928. That’s a whole lot of decades in the industry. Currently, BorgWarner is a massive company, providing parts for car companies that need to work day in and day out. That same OEM reliability and quality standard reflect the same in their aftermarket options, with way more performance.

Product Details
The EFR 6258 is the smallest and fastest spooling EFR turbocharger in the lineup. Ideal for small engines in single OR twin-turbo configuration, this is an excellent turbocharger for autocross, rally, drift, road racing, and street driven applications. The 62mm OD compressor has a 49.6mm inducer rated at 44lb/min max flow – supporting up to 440hp. This compressor wheel is versatile with very large map width for outstanding power potential, even at high boost. The low inertia 58mm Gamma-Ti turbine wheel is optimally matched for maximum response and fast spool with the FMW compressor wheel. EFR 6258 uses the smallest-sized EFR compressor housing, making fitment in the tightest engine bays possible. Ideal for use in single turbo applications for the 260-440hp range, or as twin turbo applications 400-700+hp.  Ceramic Ball Bearing only, water cooling recommended.

Compressor Specs

• Compressor Type: Forged-Milled Wheel (FMW) Extended Tip
• Compressor Wheel OD (exducer): 62mm
• Compressor Wheel Inducer: 49.6mm
• Max Flow Rate: 44 lb/min
• Built-in BOV: All EFR compressor housings incorporate an integrated BOV.
• Compressor Housing: 2.5″ inlet, 2.0″ hose coupler outlet.

Turbine Specs

• Turbine Type: Low Inertia Gamma-Ti Turbine Wheel
• Turbine Wheel OD: 58mm (recommended) OR 55mm
• Stainless Steel Sand Cast Housing
• Turbine outlet: GT-Vband (aka small 3″ v-band) ~92mm OD for all EFR turbos

Features

• Dual Row Ceramic Ball Bearings – lowest friction and fastest spool/response, most extreme durability, built-in oil control orifice – (aka oil restrictor) no restrictor can be used with EFR turbos
• Watercooled Center Section – water cooling is recommended, 14mm banjo bolts
• Double seals on both turbine and compressor end for extreme durability and resistance to any oil seepage
• Boost Control Solenoid Valve Integrated to Compressor Housing
• Integrated Speed Sensor mounting provisions
