UPR 2024-2025 Ford Ranger Raptor 3.0L Dual Valve Oil Catch Can w/ CSS (Plug N Play)
- 6oz Capacity
- Show Quality Black Anodized Finish
- Can measure 2.5" x 6" 6oz Capacity
- Prevents Oil from Entering Intake
- Exclusive 4-Stage Design Traps Oil
- Dual Valve Catch Can Technology
- Clean Side Separator (CSS) Included
- Innovative Diffuser Tube and Chamber
- High-Quality CNC Machined Billet Aluminum
- Plug N Play ™ fittings at Catch Can connections
- 5/8" Oil Resistant Continental Braided Hose included
- Improves Fuel Economy, Throttle Response & Performance
or as low as $33.33/mo with Affirm
Available
60-minute install, no drilling, no factory electronics tampering. Watch before you start.
Overview
The UPR Plug N Play Dual Valve Oil Catch Can with CSS is the full-boat PCV protection kit for the 2024-2025 Ford Ranger Raptor 3.0L. Dual-valve architecture – dirty-side catch can on one path, Clean Side Separator (CSS) on the other – traps oil vapor going IN the intake AND oil mist being pushed out of the clean side under boost. The system Raptor-specific tunes demand.
Most catch cans are just dirty-side traps – they work at idle and cruise but do nothing when the turbos spool. The Clean Side Separator (CSS) wires into the factory crankcase sensor and catches oil mist being forced OUT of the clean side when the engine is under boost – exactly when a modified Raptor pushes the most oil vapor. No check engine light. No EPS interference. No tuning required.
Fitment
| Year | Platform | Engine |
|---|---|---|
| 2024-2025 | Ford Ranger Raptor | 3.0L EcoBoost V6 |
Construction
| Component | Spec |
|---|---|
| Body material | T-6 6061 aluminum bar stock, CNC-machined |
| Finish | Black anodized |
| Capacity | 6 oz |
| Dimensions | 2.5 in x 6 in |
| Internal separation | Patented 4-stage multi-chamber diffuser |
| Hose | 5/8 inch oil-resistant Continental braided hose |
| Fittings | Plug N Play quick-release factory-style fittings – bolt-on, bolt-off, no residual marks for stock restore |
| Origin | Made in USA |
What’s Included
- Billet catch can body (black anodized, 6 oz capacity)
- 5/8 inch Continental braided hose (pre-cut)
- Billet hose end covers + plug-and-play quick-connect fittings
- Adjustable mounting hardware
- Install instructions + routing diagram
- Optional add-ons per your dropdown selections above (O-rings, magnetic drain plug, drain line kit, PCV fitting, check valves)
Installation
- Time: 60 minutes for a first-timer with basic tools.
- Difficulty: Plug-and-play. No drilling, no wiring mods, no tune.
- Tools: 10mm socket, flat-blade screwdriver for PCV quick-connect release, pliers for hose-end retention clips.
- Bracket mount: OEM hard points – bolts to factory-tapped locations.
- Remove factory fitting: Press collar inward, pull apart. Held by a retention clip – hold the ring firmly, it wants to stay seated.
- First drain: Check after 500-1000 miles. Expect 1-3 oz of captured oil on the first check. Drain interval stretches as blow-by stabilizes.
- Video walkthrough: Full visual guide embedded at the top of this page.
Companion UPR Parts
Stock up on replacement + upgrade components (also available as add-ons in the dropdowns above):
- UPR 5030 Series Replacement O-Ring Kit [2030-02] – $19.99
- UPR SS Magnetic Drain Plug [H5032-048] – $9.99
- UPR Oil Catch Can Drain Line Kit [H5032-49] – $39.99
- UPR Adjustable Hi-Flo Billet PCV Valve [5045-24] – $49.99
- UPR Pro-Series Billet Check Valve 5/8 inch [5044-03] – $49.99 each
Compliance
This part is NOT CARB-certified and is for racing / off-road use only. NOT for sale or use in California. UPR does not issue a CARB EO for this product. If you’re in California, check your state emissions requirements before ordering.
Outside California with a state-legality question? Call 805-267-9762 before ordering.
Installation & Support
Based in Thousand Oaks, CA. Shop rate $250/hr if you want us to install. Most customers do this in the driveway in under an hour. Call 805-267-9762 or tap “Talk to Expert” to coordinate. UPR authorized dealer – warranty claims route through us directly.
UPR offers unconditional lifetime warranty on all their manufactured products. Free ground shipping on orders above $99 (48 states).
